10 Row Universal Oil Cooler 330mm L x 77mm H x 51mm D. -10 Female ORB Threads

The 10-Row Universal Oil Cooler is engineered for demanding cooling tasks across engines, transmissions, and hydraulic systems. Measuring 330 mm in length, 77 mm in height, and 51 mm in depth, this compact unit delivers a high-efficiency heat-transfer surface within a tight footprint. It features -10 Female ORB connections for straightforward integration into standard oil lines.

Core specifications

• Rows: 10
• Length: 330 mm
• Height: 77 mm
• Depth: 51 mm
• Connections: -10 Female ORB threads
• BTU rating: 20,000 BTU/hour
• Max working pressure: 10 Bar (1 MPa / 145 PSI)
• Burst pressure: 25 Bar (2.5 MPa / 362 PSI)

Design and durability

• Stack-plate (modular) cooler design delivers a large heat-transfer area in a compact form
• Fully brazed on all contact surfaces inside and out for durable, leak-resistant performance
• Brazed seam resists vibrations and pulsations in demanding environments

Applications and benefits

• Versatile cooling solution for engines, transmissions, hydraulic systems, and more
• Suitable for performance vehicles, motor homes, tow vehicles, passenger cars, and motorcycles
• Improved heat rejection supports sustained performance and can contribute to extended engine and/or transmission life
• Aeroflow’s cooler range is built to withstand vibrations and pulsations in the toughest environments
• Compact footprint with a robust pressure rating ensures reliable cooling while accommodating -10 ORB connections for straightforward integration into existing lines
