GM LS1 LS2 LS3 GEN3 Flywheel Bolts
$61.70
SKU: AF37-2405
Reliable shipping
Flexible returns
GM LS1 LS2 LS3 GEN 3 Flywheel Bolts
8740 Material, Pack of 6
Kit Contains
6 x Bolts
22.05mm Under Head Length
19mm Head Diameter
11.20mm Shank Diameter
M11 x 1.50mm thread
4.15mm Shank Length
Torque Setting 74 ft.lbs (100Nm)
6 x Bolts
22.05mm Under Head Length
19mm Head Diameter
11.20mm Shank Diameter
M11 x 1.50mm thread
4.15mm Shank Length
Torque Setting 74 ft.lbs (100Nm)
Suits the following applications:
- GM LS Series Engines.
- GM LS Series Engines.
When installing a new flywheel, it is recommended to replace your flywheel bolts as the old factory ones can fatigue over time. These Aeroflow flywheel bolts are made from chrome moly 8740 for high strength compatibilities. They are black oxide to resist rust and corrosion. We recommend the use of Loctite 262 or similar so they won’t come loose over time. These bolts should be torqued down to each manufacturer’s specifications.
